Other tools
AX blank
€49.00*
00518120
AX blank
for forging yourself
approx. 50x30x160 mm
Characteristics:
Head size approx. 50x30x160 mm
approx. 2,0 kg head weight
Material C45 (forged)
easy to forge and harden
approx. 600 mm long handle
This ax blank is specially produced for us in Germany. The eye has already been inserted and corresponds to the valid DIN standard. This means that standard handles for axes and hatchets fit.
The long handle allows for a secure grip when forging and machining. After it has been individually shaped, it can simply be separated.
We chose C45 as the material because it is easy to machine and forgives one or two mistakes. C45 can also be hardened well in water or oil.
Flat chisel
From
€8.00*
00518500
chrome-molybdenum air-hardening steel,
DIN 6453, Width of blade approx. #varinfo
This chisel is primarily suitable for cold working.
extra flat chisel
€14.10*
00518501
extra flat chisel
manganese silicon steel
length 240 mm, width 26 mm, thickness 7 mm, blade 3 mm
Tip
Anvil protective pad
€5.00*
00518509
Anvil protective pad
made of aluminium,
approx. 160 x 80 x 8 mm
It stands to reason that when two forces come together one or the other will show the result of the immpact....
When these marks of the impact are left in the anvil, it is annoying. Sharp, hard and pointed tools can leave marks on the anvil.
For this reason, the protective pad is used when splitting, punching, and much more - shortly before piercing the workpiece - between the anvil and the workpiece to protect the path of the anvil.
This pad is easier and cheaper to replace than the whole anvil...
Centre Punch with carbide tip
From
€10.00*
00518550
Working edge with brazed, precision ground carbide tip
Fire Punch forged - handforged
€49.00*
00518555
Fire Punch forged - handforged
made of C75, open-die forged, hardened,
hardened and ground,
Length approx. 170 mm
For the robust application!
Stable and free-form forged, this center punch is extremely stable.
The design ensures optimal handling.
Forging and hardening the C75 steel makes these punches very hard and resilient and should the point ever become blunt it can be easily resharpened.
Characteristics:
hand forged
C75 - hard and resilient
nicely balanced
robust
First-class quality from a small German master forge.
Hofi-punch set
From
€61.00*
00518630
Hofi-punch set
Concerted pair of split chisel and punch makes work easier.
The change in length due to split and punch compensate each other. The workpiece retains his length and that makes it possible to punch many holes fast and quick.
round stake plate 4-12 mm
€137.00*
00518705
forged of quality tool steel,
approx. 400 x 34 x 20 mm (LxWxH),
with holes Ø 4, 5, 6, 8, 10,12 mm,
one side counterbored,
one side beveled,
hardened and tempered
Features:
Made of tool steel
Hardened and tempered
Forged handle
Precisely machined holes
One side countersunk
One side chamfered
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Square stake plate 5-12 mm
€156.00*
00518706
forged of quality tool steel,
approx. 400 x 34 x 20 mm (LxWxH),
with square holes 5, 6, 8, 10,12 mm,
one side beveled,
hardened and tempered
Features:
Made of tool steel
Hardened and tempered
Forged handle
Precisely machined holes
One side countersunk
One side chamfered
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Split chisel
From
€65.00*
00518710
forged of quality hot work steel W303,
hardened and tempered,
sharpened and polished,
length about 220 mm,
width of cutting edge ca. XX mm
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Hole split chisel
From
€61.00*
00518712
forged of quality hot work steel W303,
hardened and tempered,
sharpened and polished,
length about 220 mm,
width of cutting edge ~ 20 mm,
for holes XXxXX mm or ØXX mm
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Punch square
From
€55.00*
00518714
forged of quality hot work steel W303,
hardened and tempered,
sharpened and polished,
length about 220 mm,
for square holes XxX mm
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Punch universal square
€87.00*
00518718
forged of quality hot work steel W303,
smoothed,
length about 200 mm, square approx. 10x10 - 30x30 mm
Features:
Forged from hot-work steel W303
Ground and polished
Special geometry
For drilling square holes
Long service life thanks to W303 steel
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Punch universal round
€87.00*
00518720
forged of quality hot work steel W303, smoothed,
length about 200 mm, Diameter approx. 12 - 32 mm
Features:
Forged from W303 hot-work steel
Ground and polished
Special geometry
For drilling round holes
Long service life thanks to W303 steel
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Punch for square holes
From
€38.00*
00518722
handforged from high quality steel W303,
forged, smoothed and polished by hand,
Length approx. 120 mm
Features:
Forged from hot-work steel W303
Oil-hardened and tempered
Ground and polished
Special geometry
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Diagonal Punch for square hole
From
€55.00*
00518724
handforged from high quality steel W303,
forged diagonal, smoothed and polished by hand
Features:
Forged from hot-work steel W303
Oil-hardened and tempered
Ground and polished
Special geometry
These special tools are forged in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you want to learn more about Peter Reisinger and his family business, you can find more information in the "Manufacturer" tab.
Punch for hammers
€159.00*
00518726
forged of quality hot work steel W303, smoothed,
length about 280 mm,
for punching holes according to DIN.
Properties:
Forged from hot-work steel W303
Oil-hardened and tempered
Ground and polished
Long service life
Very good heat resistance
This forged tool enables easy punching and thorning of blanks according to DIN.
The thorn is forged and ground in such a way that the different "eye measurements" of the hammer head are reflected on the different lengths of the thorn.
This makes thorning easy and you get the desired eye measurement to match the hammer handles with great repeatability.
Figure 2 shows the hammer thorn and a hammer blank forged with it. The hammer blank is not included in the scope of delivery.
These special tools are forged by hand in the Reisinger forge in the heart of the lower Mühlviertel in Austria to the highest quality standards.
...and if you would like to find out more about Peter Reisinger and his family business, you can find further information here HYPERLINK "https://angele-shop.com/pages/reisinger".
Punch for hatchets
€169.00*
00518727
forged of quality hot work steel W303, smoothed,
length about 450 mm,
for punching holes according to DIN.
Properties:
Forged from hot-work steel W303
Oil-hardened and tempered
Ground and polished
Long service life
Very good heat resistance
This forged tool enables simple punching and thorning of blanks in accordance with DIN.
The thorn is forged and ground in such a way that the different "eye measurements" of the axe head are reflected on the different lengths of the thorn.
This makes it easy to thorn and you get the desired eye measurement to match the standard axe handles with great repeatability.
These special tools are forged by hand in the Reisinger forge in the heart of the lower Mühlviertel in Austria to the highest quality standards.
...and if you would like to find out more about Peter Reisinger and his family business, you can find further information here: HYPERLINK "https://angele-shop.com/pages/reisinger".
Punch for axes
€229.00*
00518728
forged of quality hot work steel W303, smoothed,
length about 490 mm,
for punching holes according to DIN.
Properties:
Forged from hot-work steel W303
Oil-hardened and tempered
Ground and polished
Long service life
Very good heat resistance
This forged tool enables simple punching and thorning of blanks according to DIN.
The thorn is forged and ground in such a way that the different "eye measurements" of the axe head are reflected on the different lengths of the thorn.
This makes it easy to thorn and you get the desired eye measurement to match the standard axe handles with great repeatability.
These special tools are forged by hand in the Reisinger forge in the heart of the lower Mühlviertel in Austria according to the highest quality standards.
...and if you would like to find out more about Peter Reisinger and his family business, you can find further information here: HYPERLINK "https://angele-shop.com/pages/reisinger".
raw piece for hammers
From
€32.00*
00518740
forged from C45,
punched, Surface untreated,
not hardened,
approx. XX x XX x XX mm,
Size of hammer-eye ca. XX x XX mm
This forged blank is ideal for forging your own hammers.
The raw piece for hammers is perforated and thorned perfectly according to DIN and after grinding or forging only has to be hardened according to your own ideas. (hardening instructions in the download area). Depending on the processing, it may happen that the eye has to be thorned again after forging. For this we recommend our hammer thorn (item no. 518726)
These special tools are forged by hand in the Reisinger forge in the heart of the lower Mühlviertel in Austria to the highest quality standards.
...and if you would like to find out more about Peter Reisinger and his family business, you can find further information here:
HYPERLINK "https://angele-shop.com/pages/reisinger".
A photo shows the different sizes in an overview.
