in different sizes   Together with this base you can easily use your ladle to heat the melt in the coal fire...   Picture 3 shows the base with pouring spoon. The pouring spoon is not included in delivery.

  two-piece construction, each 150 mm high, stable welded construction made of 5 mm sheet steel, with accurately fitting bolts, profiled inside to prevent the molding sand from slipping. including stretcher or crane bracket, including two lockable openings on the short side   Features: Sturdy welded construction Robust design Precisely fitting guides Threaded fitting bolts eliminate the need for screw clamps Profiled to prevent sand from slipping Good temperature resistance

      Must not be missing in any forge! Not only for the hobby blacksmith, but also for schools or professionals, the glow and annealing colors are part of the daily work. With this flyer or poster, these are now always at hand and ready to be seen.     Notice: The A5 size is printed as a "flyer" on high-quality paper, 350g, laminated with foil. Sizes A3 and A2 are printed on sturdy aluminum composite board.     From an order value of €25.00, the "Flyer formats" in size A5 can also be selected as a free bonus at the end of the ordering process.

Melting furnace Set 1 Set consisting of: 1x Melting furnace GTO 25 1x Transport trolley for melting oven GTO 25 1x Heat protection helmet 1x bib apron for foundries 1x leggings leather 1x heat protection mittens   Melting furnace GTO 25: propane gas crucible melting furnace GTO 25, with 2 atmospheric burners with piezo-starter and thermal security control valve. Complete with regulator and manometer, gas hose 2 m with hose breaking security, ready for connection to 11 or 33 kg gas bottles, gas consumption approx. 2 x 0.8 kg/h   Housing designed as a welded construction from stainless steel 1.4301, heat-exposed components made of special heat-resistant steel Combustion chamber suitable for standard crucibles up to 25 kg (ø 220 mm) 2-burner system results in rapid and uniform heating of the melt, well-thought-out opening lid allows to observe the melt easily.   Transport trolley for melting oven GTO 25: Made from stainless steel, outer diameter approx. 600 mm, height approx. 100 mm, maximum load capacity 90 kg.   Heat protection helmet made of high-quality glass fibre polyester, with Aluminium visor carrier with cover plate and visor made of 1 mm transparent polycarbonate.   Heat protection mittens: made from Kevlar® / Paraaramid , up to 500 °C contact heat, very resistant, usable on both sides   Leggings leather: made of durable leather with 3 buckles, length approx. 35 cm   bib apron for foundries: made of  100 % para-aramide with high-vacuum metallisation, with neck strap and tie straps for closing, length approx. 130 cm, width approx 98 cm EN ISO 11612, Standard A1/B1/C3/D3/E3/F1

Moulding Set 1 Set consisting of: 1x special moulding sand 25 kg 1x Sieve Ø 380 mm 1x Talc powder 500 g 1x moulding box 200 x 300 x 160 mm 1x shovel-type sleeker L13     Properties moulding sand: Application: Pound sand quite hard. With joint surfaces always use parting powder. Pour metal slowly into mould and vent. Leave the cast as long as possible in the mould. The surface will be smoother and the sand will last longer.   Sieve ø 380 mm: for sieving moulding sand, frame reinforced made of galavanized steel, extra strong iron wire, mesh size 3 mm.   Talc powder: Fine talc to form the separating layer of the mold between the bottom and cope.   Moulding box: two-piece construction, each 80 mm high, solid welded construction with accurately fitting bolts, inner face moulded to avoid sand from falling out.   Shovel-type sleeker: Forged steel, lancet end 30 x 17 mm, shovel end 27 x 13 mm, total length 150 mm. Ideal for post-processing or free-forming in the sand.

  Set consisting of: 1x Moulding box 100 x 200 x 100 mm 1x Moulding box 200 x 300 x 160 mm 1x Moulding box 250 x 350 x 200 mm   Features: Sturdy welded construction Robust design Precisely fitting guides Threaded fitting bolts eliminate the need for screw clamps Profiled to prevent sand from slipping Good temperature resistance     (The picture shows the profiled inner edge - this is only done in this way for molding boxes of size 200x300x160 and above. This is not needed for the small box 100x200x100, here the sand holds itself firmly enough in the mold)

Crucible Set T4 - 8 kg Set consisting of: 1x crucible 8 kg 1x crucible tong Ø 155 mm 1x crucible shank Ø 155 mm     Properties crucible: fast heating-up time all-over heat conduction slight slag accretion good chemical resistance made in germany   The capacity is specified in kg, based on the density of copper and the volume in liters. The maximum application temperature is 1450 °C. For steel and special alloys you need special high temperature crucibles.     Crucible tong: The right pair of tongs is important when gripping the crucible. The stable gripper claws grip the crucible securely and stably. The corresponding tongs must be used for smaller or larger crucibles.     Crucible shank: With the pouring holder, the melt can be safely poured into the molding box.

Crucible Set T4 - 4 kg Set consisting of: 1x crucible 4 kg 1x crucible tong Ø 115 mm 1x crucible shank Ø 115 mm     Properties crucible: fast heating-up time all-over heat conduction slight slag accretion good chemical resistance made in germany   The capacity is specified in kg, based on the density of copper and the volume in liters. The maximum application temperature is 1450 °C. For steel and special alloys you need special high temperature crucibles.     Crucible tong: The right pair of tongs is important when gripping the crucible. The stable gripper claws grip the crucible securely and stably. The corresponding tongs must be used for smaller or larger crucibles.     Crucible shank: With the pouring holder, the melt can be safely poured into the molding box.

Crucible Set T2 - 2 kg Set consisting of: 1x crucible 2 kg 1x crucible tong Ø 102 mm 1x crucible shank Ø 102 mm     Properties crucible: fast heating-up time all-over heat conduction slight slag accretion good chemical resistance made in germany   The capacity is specified in kg, based on the density of copper and the volume in liters. The maximum application temperature is 1450 °C. For steel and special alloys you need special high temperature crucibles.     Crucible tong: The right pair of tongs is important when gripping the crucible. The stable gripper claws grip the crucible securely and stably. The corresponding tongs must be used for smaller or larger crucibles.     Crucible shank: With the pouring holder, the melt can be safely poured into the molding box.

Crucible Set T1 - 1 kg Set consisting of: 1x crucible 1 kg 1x crucible tong Ø 90 mm 1x crucible shank Ø 90 mm     Properties crucible: fast heating-up time all-over heat conduction slight slag accretion good chemical resistance made in germany   The capacity is specified in kg, based on the density of copper and the volume in liters. The maximum application temperature is 1450 °C. For steel and special alloys you need special high temperature crucibles.     Crucible tong: The right pair of tongs is important when gripping the crucible. The stable gripper claws grip the crucible securely and stably. The corresponding tongs must be used for smaller or larger crucibles.     Crucible shank: With the pouring holder, the melt can be safely poured into the molding box.
