Induction

Ready for a change?

Forging with an induction device offers many advantages compared to traditional techniques such as coal or gas.

In addition to fast and efficient heating, the focus is on lower operating costs and emission-free work.

With induction devices 100% MADE in France, we offer high-quality and safe devices for hobby and professional users. You can also find everything for building coils, spare parts and accessories in our shop.

Our Angele health tip: Stay away from cheap Chinese Temu goods! Here the CE only stands for Chinese export and safety-relevant components are usually not installed.

Induction machines

induction coil

cooling

1.69 %

Induction heating device ISF7200

00171210

Induction heating device ISF7200 power 7.2 kW, 600kVA, Power connection 400V/3-ph, 16A, easy power control, operation with foot pedal, Dimensions approx. 550x350x250 mm (LxWxH), Cooling water requirement: 3-6 l/min, 3-6 bar, 15-35°C, Delivery incl. plug, foot pedal, inductor Ø 30 mm, packed in a sturdy wooden box. Device is sold without cooling 100% MADE in FRANCE Characteristics: fast, efficient heating Significantly lower costs than gas and coal selective heating possible low oxidation on the workpiece Possible to heat up to the melting point no suction necessary safe use developed and produced in France certified and tested according to European standards quick spool change easy handling robust design good spare parts availability Why no "cheap import" from China? There are inexpensive devices from the Far East, we know these devices, but strongly advise against them. Induction devices work with high voltage and large currents. Most cheap import devices do not have a real "CE" certification or tested design according to European standards. These devices work, but safe operation is not possible and, in addition to defects in the device, such as electric shock, short circuits and much more. serious accidents occur. Long-term health consequences can also occur with these devices. The efficiency of these devices is also not comparable, and the performance and service life of the power electronics are significantly lower.

in stock

€5,800.00* €5,900.00*

pcs

Induction heating device ISF24000

00171220

Induction heating device ISF24000 Power 24kW, 1000kVA, Power connection 400V/3-ph, 32A, easy power control, operation with foot pedal, Dimensions approx. 300x450x300 mm (LxWxH), Cooling water requirement: 3-8 l/min, 3-6 bar, 15-35°C, Delivery incl. plug, foot pedal, inductor Ø 30 mm, packed in a sturdy wooden box. Device is sold without cooling 100% MADE in FRANCE Characteristics: fast, efficient heating Significantly lower costs than gas and coal selective heating possible low oxidation on the workpiece Possible to heat up to the melting point no suction necessary safe use developed and produced in France certified and tested according to European standards quick spool change easy handling robust design good spare parts availability Why no "cheap import" from China? There are inexpensive devices from the Far East, we know these devices, but strongly advise against them. Induction devices work with high voltage and large currents. Most cheap import devices do not have a real "CE" certification or tested design according to European standards. These devices work, but safe operation is not possible and, in addition to defects in the device, such as electric shock, short circuits and much more. serious accidents occur. Long-term health consequences can also occur with these devices. The efficiency of these devices is also not comparable, and the performance and service life of the power electronics are significantly lower.

Available in 30 days, delivery time 1-3 days

€13,800.00*

pcs

Copper pipe Ø 8 mm

00171400.08

Copper pipe Ø 8 mm 8 x 1.0 mm, bendable, suitable for ISF24000 Easily bendable copper tubing, ideal for making inductors. This means that coils for induction devices can be built quickly and easily.

in stock

From €4.41*

Compression ferrule for copper pipe Ø 6 mm

00171420.06

Compression ferrule for copper pipe Ø 6 mm suitable for ISF7200

in stock

€1.50*

Details

Union nut M 12x1.0

00171430.08

Union nut M 12x1.0 suitable for ISF7200, ISF24000

in stock

€2.00*

Details

Pre-assembly stud M 12x1

00171440.08

Pre-assembly stud M 12x1 for stainless steel, brass M, aluminium unions The assembly socket is used to pre-assemble the clamping ring and the connecting nut onto the copper pipe. This ensures proper assembly and protects the connections on the device itself. Instructions: Clamp the pre-assembly stud in a vise. Screw on the nut connection. Push the tube into the nut connection. Tighten the union nut approx. 1 1/2 turns with an open ended spanner (mechanical stop). Final assembly in the equipment approx. 1/4 turn. Keep the flat metal surface clean. Occasional lubrification of the thread and the flat metal surface facilitate pre-assembly.

in stock

€39.00*

Details

Protective hose copper pipe 6 mm

00171450.06

Protective hose copper pipe 6 mm Inside diameter approx. 6 mm High-temperature-resistant protective sleeve made of fiberglass/glass fiber. To protect the copper tube of the induction coil from slag, sparks or melt. The protective hose is crucial for optimal adhesion of the mortar and prevents the mortar from flaking off prematurely during later operation.

in stock

From €1.80*

Glass fiber tape, 1 m

00171455.1

Glass fiber tape, 1 m approx. 0,1 mm thick High temperature resistant fiberglass tape. Prevents fraying when cutting the protective hose.

in stock

€8.90*

Details

Cooling for induction device CHW26

00171510

Cooling for induction device CHW26 2.6 kW cooling capacity, flow rate coolant 5-40 l/min, Delivery pressure 0.5 - 3.8 bar. Suitable for the device ISF7200 100% MADE in Italy Characteristics: reliable cooling of the device and the coils Industrial quality reliable supply of spare parts easy handling robust design

Available in 30 days, delivery time 1-3 days

€3,400.00*

pcs

Cooling for induction device CHW56

00171511

Cooling for induction device CHW56 5,6 kW cooling capacity, flow rate coolant 5-32 l/min, Delivery pressure 0.5 - 3.5 bar. Suitable for the device ISF724000 100% MADE in Italy Characteristics: reliable cooling of the device and the coils Industrial quality reliable supply of spare parts easy handling robust design

Available in 30 days, delivery time 1-3 days

€5,200.00*

pcs

$Refractory Mortar 1600 °C, 1 kg$

Refractory Mortar 1600 °C, 1 kg

59104050.01

Refractory Mortar 1600 °C, 1 kg for "plastering" the induction coil, Temperature resistant up to approx. 1600 °C This mortar is ideal for protecting the induction coil. After covering the copper tube with a glass fiber tube, the finished coil is dipped into the mortar or "plastered" with it. This protects it from slag or melt and significantly increases its service life. Characteristics: high adhesion thin layer thickness (approx.1-3 mm) easy processing high thermal shock resistance max. application temperature approx. 1600°C good resistance to borax or other fire welding agents Scope of application: induction coil Repair work in stoves/hearths Notice: Mixing ratio approx. 250 ml Water per 1 kg Refractory Mortar Attention, our refractory concrete (59104001) is not suitable for plastering the induction coil.

in stock

€9.90*

Details
