Fans
"It's not about size"
The suitability of a fan for use in a forge fire is not so much determined by sufficient power consumption, i.e. a "high wattage". Rather, the fan must be adapted to the application in terms of volume flow and pressure. Each fan has a specific characteristic curve, which you can also find for the respective fans in the download area.
If the old fan is defective after 50 years, it usually makes sense to switch to a new model. The new fans offer better performance with low power consumption and low noise. Our fans are all industrial quality and suitable for continuous use!
If you can't find the right fan or you need help choosing - we're happy to help!
400/230 V, 50 Hz, 370 W three-phase, 2800 U/min, 0,98/1,7 A, air debit 6,0 m³/min, pression 1200 Pa
gear train with handle air debit appr. 1 m³/min, 500 Pa at 140 r.p.m.
230 V, 50 Hz, 30 W, single-phase, air debit max. 2,5 m³/min, pression max. 335 Pa
400 V, 50 Hz, 45 W three-phase, with switch, air debit max. 2,5 m³/min, pression max. 335 Pa
single-phase 230 V, 50 Hz, 30 W, with switch, power cable 3 m, plug (type F), air debit max. 2,5 m³/min, pression max. 335 Pa
230 V, 50 Hz, 30 W single-phase, with switch, power cable 3 m, plug (type F), air debit max. 2,5 m³/min, pression max. 335 Pa Note: The crowned pulley is not included and must be ordered separately if required (see accessories).
230 V, 50 Hz, 85 W, single-phase, with power cable 3 m and plug switch, air debit max. 4,1 m³/min, pression max. 270 Pa Air intake fan, suitable for smaller forge fires, portable forges, homemade stoves, etc. or simply for heating up a barbecue ;) Features: Robust design Sufficient air intake for fire bowls Quiet Plug & Play, delivered ready to plug in European production Small - powerful - inexpensive This ATV 125 fan replaces the previous ENG 1-2.6 fan and fits to the current lower part of the hobby-forge. With an adapter, the ATV 125 also fits with the old hobby forges (built before December 2018 with fan ENG 1-2.6).
400 V, 50 Hz, 50 W three-phase, with switch, air debit 2,6 m³/min, pression 640 Pa Suitable for 1 fire. Industrial fan, built for continuous operation. Features: Very smooth running Very quiet operation Energy-efficient due to high efficiency Balanced impellers Robust design Cast, stable housing Bi-metal motor protection Ideal for blacksmith forges Including switch Industrial motor Radial fan Good spare parts availability For one fire
230 V, 50 Hz, 75 W single-phase, air debit 4,9 m³/min, pression 1000 Pa Suitable for 1-2 fires. Industrial fan, built for continuous operation. Features: Very smooth running Very quiet operation Energy-efficient due to high efficiency Balanced impellers Robust design Cast, stable housing Bi-metal motor protection Ideal for blacksmith forges Including switch Industrial motor Radial fan Good spare parts availability For one upt to two fires
400 V, 50 Hz, 75 W, three-phase, air debit 5,0 m³/min, pression 1000 Pa Suitable for 1-2 fires. Industrial fan, built for continuous operation. Features: Very smooth running Very quiet operation Energy-efficient due to high efficiency Balanced impellers Robust design Cast, stable housing Bi-metal motor protection Ideal for blacksmith forges Including switch Industrial motor Radial fan Good spare parts availability For one upt to two fires
400 V, 50 Hz, 90 W, three-phase, air debit 5,3 m³/min, pression 930 Pa Suitable for 1-2 fires. Industrial fan, built for continuous operation. Features: Very smooth running Very quiet operation Energy-efficient due to high efficiency Balanced impellers Robust design Cast, stable housing Bi-metal motor protection Ideal for blacksmith forges Including switch Industrial motor Radial fan Good spare parts availability For one upt to two fires
400 V, 50 Hz, 300 W three-phase, with switch, air debit 11 m³/min, pression 2000 Pa Suitable for 2-4 fires. Industrial fan, built for continuous operation. Features: Very smooth running Very quiet operation Energy-efficient due to high efficiency Balanced impellers Robust design Cast, stable housing Bi-metal motor protection Ideal for blacksmith forges Including switch Industrial motor Radial fan Good spare parts availability For 2-4 fires
400 V, 50 Hz, 370 W three-phase, air debit 11 m³/min, pression 1800 Pa Suitable for 2-4 fires. Industrial fan, built for continuous operation. Features: Very smooth running Very quiet operation Energy-efficient due to high efficiency Balanced impellers Robust design Cast, stable housing Bi-metal motor protection Ideal for blacksmith forges Including switch Industrial motor Radial fan Good spare parts availability For 2-4 fires
